C-Series

Picking Robots for Optimized Storage and Retrieval!
Download Product DatasheetDownload Product Datasheet
Quicktron's C-Series Picking Robots are versatile mobile robots that revolutionize warehousing operations. Its intelligent design ensures efficient space utilization by vertically storing goods on racks at an impressive height of 10m, you'll unlock unparalleled accuracy and control over your stock levels while optimizing storage capacity. With intelligent navigation, high-speed and precise picking & retrieving capabilities, along with seamless integration, and robust safety features, the C- Series enhances productivity, and speed and reduces labor costs across industries.
High-Quality Products
Advanced Safety Sensors
Flexibility
Wide Picking Range
Max. Height 10m

Types of C56 Gripping Modules

C56 - Telescopic Gripper Module

In this gripping module bins/cases are retrieved and placed using mechanical gripping arms. In this mechanism the telescopic arms extend, secure the bins with clips, and form a box shape during retraction. Minimum 120mm spacing is required between boxes during storage for a smooth retraction.

C56 - Vacuum Gripper Module

In the vacuum suction mechanism, the robot extends its picking arm which is equipped with two suction cups in front to retract the boxes. This advanced technology eliminates the need for spacing while stacking the bin/boxes, further optimizing storage capacity.

C56 Mast module

The C56A(C)-B series robot offers two mast modules: single-level and double-level. The single-level mast has a fixed height range, while the double-level mast can extend from a lower height to its maximum height and also retract from its maximum height to a lower position, enabling it to navigate through spaces with limited vertical clearance.

Picking Method
Mast Type
C56A(S)-BD1
Rated load
50kg
Lifting Height
6500mm
Picking Method
Telescopic Gripper
Navigation Mode
QR Code
Case/Bin Size
(300~650)*(210~440)*(150~400)mm
Positioning Accuracy
±10mm
Storage Layers on Robot
6(1-10)
Max no-load speed
1.8m/s
Battery Life / Charge
6-8h
C56A(S)-BS1
Rated load
50kg
Lifting Height
6500mm
Picking Method
Telescopic Gripper
Navigation Mode
QR Code
Case/Bin Size
(300~650)*(200~500)*(150~400)mm
Positioning Accuracy
±10mm
Storage Layers on Robot
6(1-10)
Max no-load speed
1.8m/s
Battery Life / Charge
6-8h
C56A(S)-BV1
Rated load
30kg
Lifting Height
6500mm
Picking Method
Vacuum Gripper
Navigation Mode
QR Code
Case/Bin Size
(300~600)*(400~420)*(280~600)mm
Positioning Accuracy
±10mm
Storage Layers on Robot
6(1-10)
Max no-load speed
1.8m/s
Battery Life / Charge
6-8h
C56A(S)-BX1
Rated load
30kg
Lifting Height
6500mm
Picking Method
Vacuum Gripper
Navigation Mode
QR Code
Case/Bin Size
(300~600)*(400~420)*(280~600)mm
Positioning Accuracy
±10mm
Storage Layers on Robot
6(1-10)
Max no-load speed
1.8m/s
Battery Life / Charge
6-8h
C56A(S)-BD2
Rated load
50kg
Lifting Height
7800mm
Picking Method
Telescopic Gripper
Navigation Mode
QR Code
Case/Bin Size
(300~650)*(210~440)*(150~400)mm
Positioning Accuracy
±10mm
Storage Layers on Robot
6(1-10)
Max no-load speed
1.8m/s
Battery Life / Charge
6-8h
C56A(S)-BS2
Rated load
50kg
Lifting Height
7800mm
Picking Method
Telescopic Gripper
Navigation Mode
QR Code
Case/Bin Size
(300~650)*(200~500)*(150~400)mm
Positioning Accuracy
±10mm
Storage Layers on Robot
6(1-10)
Max no-load speed
1.8m/s
Battery Life / Charge
6-8h
C56A(S)-BV2
Rated load
30kg
Lifting Height
7800mm
Picking Method
Vacuum Gripper
Navigation Mode
QR Code
Case/Bin Size
(300~600)*(400~420)*(280~600)mm
Positioning Accuracy
±10mm
Storage Layers on Robot
6(1-10)
Max no-load speed
1.8m/s
Battery Life / Charge
6-8h
C56A(S)-BX2
Rated load
30kg
Lifting Height
7800mm
Picking Method
Vacuum Gripper
Navigation Mode
QR Code
Case/Bin Size
(300~600)*(400~420)*(280~600)mm
Positioning Accuracy
±10mm
Storage Layers on Robot
6(1-10)
Max no-load speed
1.8m/s
Battery Life / Charge
6-8h
Download Product Datasheet
Need More Details?
Connect with our product manager to get complete specifications
